Rugged Tablets
HOTUS HTYJ08A 8-inch Rugged Tablet, Core i5 or i7
- Processor & OS:
- Intel Core 10th Generation i5-10210Y / i7-10510Y Quad-Core Processor | Windows 10 Pro / Windows 11 Pro
- Display:
- 8-inch IPS Full HD Touchscreen (1200 x 1920 Resolution, 560nits High Brightness, 10-Point Capacitive Touch, Hardness Level: 7H, Supports Stylus & Wet-Hand Operation)
- Durability:
- IP67 Dustproof & Waterproof Rating, MIL-STD-810G Certified, 1.22m Drop Resistance, Double-Layer Solid Body, Operating Temp: -20°C to 55°C, Gross Weight: 1.8KG
- Battery:
- 7.6V 3500mAh Removable Battery | Power Adaptor: AC 100V~240V / Output DC 19V 3.42A
- Connectivity:
- Wi-Fi 6 (802.11ax), Bluetooth 5.0, Global 4G LTE Full Netcom, BDS/GPS/GLONASS Satellite Positioning
- OEM / ODM / JDM Available：
- Yes
- Warranty & After-Sales：
- HOTUS provides a 3-Year Limited Warranty
- Certification：
- MIL-STD-810G, CE, FCC, 3C, IP67
OEM / ODM welcome . Factory-direct . Response within 24h
HOTUS HTYJ08A Key Features & Highlights
Intel Core i5/i7 High-Performance Computing
Powered by Intel 10th Gen Core i5 or i7 processors and Windows Pro, offering powerhouse desktop-grade processing in a compact form factor.
IP67 Waterproof & Double-Layer Solid Body
Engineered with IP67 waterproofing, MIL-STD-810G drop resistance, and an ultra-sturdy double-layer chassis for extreme field durability.
Compact 8-Inch 560nits Sunlight-Readable Display
Features an 8-inch 560nits high-brightness touchscreen with 7H hardness, ensuring excellent visibility and portability in outdoor environments.
Comprehensive Full-Size I/O Interfaces
Equipped with built-in RJ45 Ethernet, USB Type-A/C ports, Mini HDMI, and a 12Pin Pogo-pin connector for versatile peripheral connectivity.
HOTUS HTYJ08A 8-Inch High-Performance Industrial Rugged Windows Tablet Technical Specifications
| Product Model | HTYJ08A 8-Inch High-Performance Industrial Rugged Windows Tablet |
|---|---|
| Processor & GPU | Intel Core 10th Generation i5-10210Y / i7-10510Y Quad-Core Processor | Graphics: Intel UHD Graphics |
| RAM & Storage | Standard: High-Speed RAM + SSD Storage (Supports M.2 Extension) |
| Display & Touch | 8-inch IPS Touchscreen (1200 x 1920 Resolution, 560nits High Brightness, 10-Point Capacitive Touch, Hardness Level: 7H, Supports Stylus & Wet-Hand Operation) |
| Camera System | 5MP Front Camera + 8MP Rear Autofocus Camera with LED Flashlight |
| Battery System & Power | 7.6V 3500mAh Removable Battery | Power Adaptor: AC 100V~240V / Output DC 19V 3.42A |
| Protection & Military Standard | IP67 Dustproof & Waterproof, MIL-STD-810G Certified, 1.22m Drop Resistance, Double-Layer Solid Body, Operating Temp: -20°C to 55°C |
| Interfaces & Connectivity | Audio x1, Mini HDMI x1, USB Type-A x1, USB Type-C x1, DC IN x1, RJ45 Ethernet x1, TF Card Slot x1, SIM Slot x1, 12Pin Pogo-Pin x1 | Wi-Fi 6 + Bluetooth 5.0 + Global 4G LTE |
| Dimensions & Weight | 23.8cm x 16cm x 2.5cm | Gross Weight: approx. 1.8KG |
| Data Capture & Security (Optional) | Optional 1D/2D Barcode Scanner, UHF RFID, Fingerprint Reader, 13.56MHz NFC, TPM2.0 Hardware Security |
| OS | Windows 10 Pro / Windows 11 Pro |
| Key Points | Intel Core i5/i7 Flagship Power // Compact 8-Inch 560nits Display // Double-Layer Solid Body // IP67 & MIL-STD-810G // Rich Physical Interfaces (RJ45, HDMI, USB) |
HOTUS HTYJ08A Rugged Windows Tablet Applications & Use Cases
Widely deployed in mobile field service, vehicle-mounted fleet diagnostics, outdoor surveying, utility meter reading, and industrial automation control.
HOTUS HTYJ08A Rugged Tablet OEM / ODM Customization
Customize interfaces, firmware, OS, boot logo, branding & packaging. 72-hour rapid prototyping, 8D quality control, scalable manufacturing.
1.1 Appearance & Structure Customization
• Custom body color, size, protective structure, laser engraving, logo silk printing, nameplate and IP65/IP67/IP68 waterproof & dustproof grade
1.2 Hardware & Interface Customization
• Custom I/O ports (CAN, GPIO, PoE, RS485/RS232, DI/DO), BIOS settings, RAM/ROM, wide-temperature module, power supply, detachable battery, fan/fanless cooling, 1D/2D scanner, NFC, RFID, fingerprint, GPS/Beidou, 4G/5G, Wi-Fi 6 and Bluetooth
1.3 System & Pre-installation Customization
• Pre-install Windows IoT/Ubuntu/Linux system, custom system image, driver integration, customer software pre-installation, system simplification, permission lock, auto-start configuration, system activation, partition preset and firmware packaging
1.4 Packaging & Material Customization
• Neutral/custom brand packaging, custom carton, color box, buffer lining, manual, certificate, labels, power cable, shoulder strap, wrist strap, serial cable and full accessory kits
HOTUS HTYJ08A Rugged Tablet Certification & Compliance
CEFCCRoHSISO 9001
HOTUS HTYJ08A 8-Inch Rugged Windows Tablet - Frequently Asked Questions (FAQ)
1. What processor powers the HOTUS HTYJ08A rugged tablet?
The HTYJ08A is powered by high-performance Intel Core 10th Generation i5-10210Y or i7-10510Y quad-core processors.2. Which operating system does the tablet support?
It comes pre-installed with Windows 10 Pro, with full upgrade compatibility for Windows 11 Pro.3. What display quality and brightness does the HTYJ08A offer?
It features an 8-inch IPS Full HD touchscreen (1200x1920 resolution) with an ultra-bright 560nits backlight and 7H scratch resistance.4. What rugged protection standards does the device hold?
It is IP67 dustproof and waterproof certified and meets MIL-STD-810G military standards featuring a double-layer solid body design.5. What physical ports are available directly on the tablet?
Despite its compact 8-inch size, it includes a full set of ports: RJ45 Ethernet, USB Type-A, USB Type-C, Mini HDMI, Audio jack, and DC power input.6. Does the HTYJ08A support barcode scanning or RFID modules?
Yes, it can be customized with optional 1D/2D barcode scanners, UHF RFID modules, fingerprint readers, and 13.56MHz NFC.7. What wireless connectivity features are included?
It features Wi-Fi 6 (802.11ax), Bluetooth 5.0, global 4G LTE Full Netcom, and integrated BDS/GPS/GLONASS satellite navigation.8. What are the physical dimensions and weight of the tablet?
The compact device measures 23.8 x 16 x 2.5cm and has a gross weight of approximately 1.8KG.9. Can it be connected to vehicle docks or charging stations?
Yes, it supports dedicated desktop cradles and vehicle-mounted charging docks via its integrated 12Pin Pogo-pin connector.10. What warranty and OEM/ODM services are provided by HOTUS?
HOTUS provides a 3-Year Limited Warranty and full OEM/ODM customization services (custom hardware branding, specialized I/O ports, and software integration).Warranty & After-Sales Service
Reliable support from purchase to long-term operation. HOTUS provides a 3-Year Limited Warranty for industrial PDA, rugged tablets and Mini PCs, together with lifetime technical support to help keep your equipment stable and operational.
Our After-Sales Commitment
3 Years Limited WarrantyThree-year limited warranty for the main units of industrial PDA, rugged tablets and Mini PCs. | Lifetime Technical SupportTechnical consultation, device setup, troubleshooting and system compatibility support throughout the product lifecycle. | Professional Repair & ReplacementQualifying warranty failures are supported with inspection, repair or replacement of defective components according to the policy. |
Warranty Coverage
3-Year Limited Warranty
The warranty applies to new genuine products used under normal commercial or industrial conditions. The warranty period starts from the date the customer receives and accepts the product.
| Product | Main Unit Warranty | Accessories Warranty |
|---|---|---|
| Industrial PDA | 3 Years | 1 Year |
| Rugged Tablet | 3 Years | 1 Year |
| Mini PC | 3 Years | 1 Year |
Core hardware components such as the original hard drive, memory, motherboard, CPU, touch module and rugged sealing components follow the main unit's 3-year warranty. Common consumable accessories such as power adapters, data cables, external cables and standard buttons are covered for 1 year.
