X8 Series Handheld Label & Thermal Printing PDA Mobile Terminal
Core Positioning: Engineered for extreme enterprise mobility, the X8 series combines a high-performance Android 14 rugged handheld computer with an integrated high-speed thermal label printer and an industrial-grade 50mm wide paper roll compartment. The ultimate all-in-one solution for last-mile delivery, retail shelf-edge labeling, and warehouse inventory tracking.
✨ Key Features & Technical Advantages
Core Highlight I: Extra-Wide 50mm Thermal Paper Roll Bin
Massive Capacity & High Efficiency: Unlike standard mobile printers limited to narrow rolls, the X8 features a meticulously engineered 48mm to 50mm wide paper compartment with a larger outer diameter capacity. This allows field operators to load heavy-duty thermal adhesive labels and receipt rolls that last significantly longer.
Business Value: Dramatically minimizes roll-change frequency during peak logistics sorting or massive retail shelf-markdown campaigns, ensuring continuous, interruption-free workflow and maximum operational productivity.
Core Highlight II: Ergonomic Anti-Drop & Rugged Grip Architecture
All-Day Comfort Meets Industrial Toughness: Designed around human factors engineering, the device features a contoured, non-slip grip profile that molds naturally to the hand's palm curve, effectively distributing weight and eliminating wrist strain during intense, multi-shift mobile scanning.
Business Value: Wrapped in industrial shock-absorbing elastomers and certified for multi-drop resistance on concrete floors, it guarantees supreme reliability in harsh warehouses, loading docks, and outdoor delivery environments.
Built-in High-Speed Printer
Empowers field operators with instant on-site label and receipt printing for shipping waybills and shelf tags.
Next-Gen Android 14 Platform
Driven by a robust 64-bit octa-core chipset, delivering ultra-responsive multitasking and enterprise security.
Sunlight-Readable Touchscreen
5.5-inch high-definition IPS display supporting wet fingers and heavy industrial glove operation.
Extended Dual-Cell Power
Flexible high-capacity battery options (up to 10600mAh equivalent) to guarantee multi-shift endurance.
Comprehensive Technical Specifications
| Specification Category | X8 Standard Edition (V1.5) | ⚡ X8 Printer + ID + 2D (V1.6) / X8P / UHF |
|---|---|---|
| Operating System | Android 14 Enterprise Ready | Android 14 Enterprise Ready |
| Processor Architecture | High-Performance Octa-Core 64-bit CPU | High-Performance Octa-Core 64-bit CPU |
| Memory Configuration | 4GB RAM + 64GB ROM | 4GB + 64GB (Scalable to 6GB+128GB / 8GB+128GB) |
| Display Panel | 5.5-inch IPS High-Brightness Panel (1440 × 720 Native Resolution) | |
| Touch Interface | Industrial Capacitive Touch, Optimized for Wet Touch & Heavy Gloves | |
| Printer & Paper Capacity | Built-in High-Speed Thermal Printer | Supports 48mm ~ 50mm Width Thermal Label Rolls | |
| Power & Battery Spec | 7.6V 2750mAh Dual-Cell (Equivalent to 5500mAh@3.8V) | X8P Large Battery: 7.6V 5300mAh Removable (Equivalent to 10600mAh@3.8V) |
| Optical Camera System | Front 5MP / Rear 13MP with Autofocus and High-Intensity Flashlight | |
| Protection & Form Factor | IP54 Industrial Sealing & Ergonomic Anti-Drop Design | Dimensions: ~178×76×18.5mm | Weight < 500g | |
Ideal Target Application Environments
Express Delivery & Logistics
Streamlines waybill printing, package sorting, proof-of-delivery processing, and real-time route dispatch tracking.
Retail Chains & Supermarkets
Perfect for shelf-edge price re-marking, promotional markdown tagging, inventory checks, and mobile check-out receipts.
Fixed Asset Tracking
Enables rapid asset barcode tagging, warehouse material labeling, and mobile inspection data verification.
